Built on advanced linear cryocooler, the C1010H HOT cooled infrared detector features a 1024×768 resolution with a 10μm pixel size. While ensuring excellent performance, its focal plane operating temperature is increased to 150K, delivering outstanding SWaP (small size, light weight, low power consumption) performance. It fully meets market demands for long-duration operation, compact system integration, and high-definition thermal imaging.
1024×768 megapixel resolution for a wide field of view
10μm small pixel size for high spatial resolution and long-range detection
Cooling time as low as 3 minutes
Stable power consumption down to 3W
Mean Time To Failure (MTTF) up to 25,000 hours
| Model | C1010H HOT MWIR Cooled Infrared Detector |
| Sensitive Material | T2SL |
| Resolution | 1024×768 |
| Pixel Size | 10μm |
| Spectral Response | 3.7±0.2μm~4.8±0.2μm |
| Typical NETD | 20mK(F2) 25mK(F4) |
| Max. Frame Rate | 100Hz |
| Effective Pixel Rate | ≥99.5% |
| Response Non-uniformity | ≤8% |
| Operating Temperature | -45℃~+71℃ |
| Cryocooler | LS711H |
| Cooling Time(23℃) | ≤3min |
| Max. Power Consumption(71℃) | ≤12W |
| Steady Power Consumption(23℃) | ≤3W |
| Size(mm) | Cryocooler: φ26×55.8 |
| Dewar: 33×37.5×70 | |
| Weight(g) | ≤235 |
