The C1207M HD MWIR cooled infrared detector features a 1280×1024 megapixel focal plane array with an industry-leading 7.5μm pixel size—delivering four times the pixel count of conventional 640×512 detectors over the same target area, revealing significantly more image detail. Despite its high-resolution imaging capability, the device maintains a compact form factor. Combining high resolution, superior performance, and exceptional reliability, the C1207M is an ideal infrared core component for applications requiring outstanding long-range detection and fine image detail recognition.
1280×1024 megapixel high-definition imaging for a wider field of view
Ultra-small 7.5μm pixel size delivers high spatial resolution and extended detection range
Smaller size and lighter weight
Lower power consumption for easy system integration
Customizable F-number
Mass production with excellent consistency
| Model | C1207M HD MWIR Cooled Infrared Detector | |
| Sensitive Material | MCT | |
| Resolution | 1280×1024 | |
| Pixel Size | 7.5μm | |
| Spectral Response | 3.7μm±0.2μm～4.8μm±0.2μm | |
| Working Mode | Snapshot ITR/IWR Integration Modes Windows Mode Anti-blooming | |
| Charge Capacity | 2.5Me-(ITR) 2.4Me-(IWR) | |
| Dynamic Range | ≥76dB | |
| Output Channel | 4 or 8 Channels; Up to 20MHz per output | |
| Max. Frame Rate | 100Hz | |
| Typical NETD | 25mK(F2/F4) | |
| Effective Pixel Rate | ≥99.5% | |
| Response Non-uniformity | ≤8% | |
| Configurable Cryocooler | RS046 | |
| Steady Power Consumption(23℃) | ≤6.5W | |
| Max. Power Consumption(71℃) | ≤15W | |
| Power Supply | 32V DC | |
| Cooling Time(23℃) | ≤5min30s | |
| Weight(g) | ≤350 | |
| Maximum Size (mm) | 120×46.5×81.5 | |
| Operating Temperature | -45℃～+71℃ | |
