The iTL1208 is a compact 8μm megapixel infrared camera core engineered for next-generation SWaP optimization. Measuring just 22.6×22.6×34.5mm and weighing only 34.5g (including a 12mm lens), it delivers exceptional portability without compromising performance.
Featuring a megapixel large-format detector, the iTL1208 provides high-definition thermal imaging with industry-leading 8μm pixel size allowing for higher integration density. With NETD down to 30mK and enhanced by advanced image optimization algorithms, it captures finer thermal details with greater clarity. Designed especially for handheld devices and mobile platforms, it is ideal for security surveillance, industrial inspection, firefighting, rescue operations, and other applications requiring compact yet high-resolution thermal imaging.
Compact size of 22.6×22.6×34.5mm and a weight of 34.5g (including a 12 mm lens)
Among the highest levels of integration in its class
8μm ultra-small pixel size with 1280×1024 resolution, delivering fine detail and clear images
Typical NETD≤30mK, enabling reliable detection of subtle temperature differences
Multiple optical lens options available to meet diverse application requirements
Supports MIPI CSI image output interface
RAW and YUV image data output, with control via serial port/I2C
| Model | iTL1208 |
| IR Detectors Indicators | |
| Sensitive Material | VOx |
| Resolution | 1280×1024 |
| Pixel Size | 8μm |
| Spectral Response | 8μm ~ 14μm |
| Typical NETD | ≤30mK |
| Image Processing | |
| Digital Frame Rate | 25/30Hz |
| Start-up Time | ≤6s |
| Digital Video | RAW/YUV |
| Image Algorithm | NUC/3DNR/DNS/DRC/EE |
| Image Display | 10 Types (White Hot/Lava/Iron Red/Hot Iron/Medical/Arctic/Rainbow 1/Rainbow 2/Tint/Black Hot) |
| PC Software | |
| PC Software | Module Control & Video Display |
| Electrical | |
| Standard External Interface | 34Pin_Connector Interface: BP04SD-34-0065-R0 |
| Communication Interface | TTL-232/I2C |
| Digital Video Interface | MIPI-CSI |
| Supply Voltage | 4.5-5.5V |
| Typical Power Consumption | 0.8W |
| Mechanical | |
| Size(including lens) | With 5mm lens: 22.6mm×22.6mm×50mm (lens outer diameter Φ37mm) With 10mm lens: 22.6mm×22.6mm×45.3mm (lens outer diameter Φ33mm) With 12mm lens: 22.6mm×22.6mm×34.5mm (lens outer diameterΦ26.6mm) With 17mm lens: 22.6mm×22.6mm×35.4mm (lens outer diameter Φ27mm) With 25mm lens: 22.6mm×22.6mm×44.2mm (lens outer diameter Φ33mm) With 35mm lens: 22.6mm×22.6mm×50.9mm (lens outer diameter Φ43.2mm) |
| Weight (including lens) | 89.6±5g(5mm lens) 69.7±5g(10mm lens) 34.5±5g(12mm lens) 39.3±5g(17mm lens) 80.0±5g(25mm lens) 87.2±5g(35mm lens) |
| Environmental Adaptability | |
| Operating Temperature | -40℃~+70℃ |
| Storage Temperature | -45℃~+85℃ |
| Humidity | 5%~95%, non-condensing |
| Vibration | 5.35grms, Random Vibration, 3-axis |
| Impact | Half Sine Wave, 40g/11ms, Impact Direction X Axis, 3 times |
| Certification | ROHS2.0/REACH |
| Optical Lens | Fixed Focus Athermal: 5/10/12/17/25/35mm |
