The iTL608 infrared thermal camera core features an ultra-compact form factor of 13 × 13 × 18.3 mm—approximately the size of a thumb—and weighs only 6.7 g, comparable to the weight of two coins, pushing the limits of lightweight and compact design once again. Equipped with a VOx infrared detector, the 640 × 512/8μm iTL608 delivers a high thermal sensitivity of NETD≤30mK. Operating in the 8–14μm LWIR, it enables precise detection of typical ambient-temperature targets. The core supports a fast startup time of ≤ 6 seconds and frame rates of 30 Hz/50 Hz, while integrated NUC and 3DNR algorithms optimize image uniformity and overall image quality. Designed for reliable operation in demanding environments, the iTL608 functions across a wide temperature range of –40°C to +70°C, making it well suited for handheld devices other portable platforms, addressing application needs in security surveillance, temperature measurement, and night vision.
Compact size of 13×13×18.3mm and a weight of 6.7±1.5g (including a 6 mm lens)
Among the highest levels of integration in its class
8μm ultra-small pixel size with 640×512 resolution, delivering fine detail and clear images
Typical NETD≤30mK, enabling reliable detection of subtle temperature differences
Multiple optical lens options available to meet diverse application requirements
Supports multiple image output interfaces, including MIPI/USB 2.0/BT.656
RAW and YUV image data output, with control via serial port/I2C
| Model | iTL608 |
| IR Detectors Indicators | |
| Sensitive Material | VOx |
| Resolution | 640×512 |
| Pixel Size | 8μm |
| Spectral Response | 8μm ~ 14μm |
| Typical NETD | ≤30mK |
| Image Processing | |
| Digital Frame Rate | 30/50Hz |
| Start-up Time | ≤6s |
| Digital Video | RAW/YUV/TMP |
| Image Algorithm | NUC/3DNR/DNS/DRC/EE |
| Image Display | 10 Types (White Hot/Lava/Iron Red/Hot Iron/Medical/Arctic/Rainbow 1/Rainbow 2/Tint/Black Hot) |
| PC Software | |
| Software | Module Control & Video Display |
| Electrical | |
| Standard External Interface | 34Pin_Connector Interface: BP04SD-34-0065-R0 |
| Communication Interface | TTL-232/USB2.0/I2C |
| Digital Video Interface | MIPI/USB2.0/BT.656 |
| Supply Voltage | 4-5.5V |
| Typical Power Consumption | 0.4W |
| Mechanical | |
| Size(including lens) | With 6mm lens: 13 × 13 × 18.3 mm (lens outer diameter Φ12.3 mm) With 8.7mm lens: 13 × 13 × 19.8 mm (lens outer diameter Φ15.6 mm) With 16.7mm lens: 13 × 13 × 27.9 mm (lens outer diameter Φ22.2 mm) With 30mm lens: 13 × 13 × 39 mm (lens outer diameter Φ36 mm) |
| Weight (including lens) | 6.7±1.5g(6mm lens) 7.5±1.5g(8.7mm lens) 17±1.5g(16.7mm lens) 42.7±1.5g(30mm lens) |
| Environmental Adaptability | |
| Operating Temperature | -40℃~+70℃ |
| Storage Temperature | -45℃~+85℃ |
| Humidity | 5%~95%, non-condensing |
| Vibration | 5.35grms, Random Vibration, 3-axis |
| Impact | Half Sine Wave, 40g/11ms, Impact Direction X Axis, 3 times |
| Certification | ROHS2.0/REACH |
| Optical Lens | Fixed Focus Athermal: 6/8.7/16.7/30mm |
